| Overige specificaties |
|---|
| Minimum systeemeisen voor Macintosh: | Mac OS X v10.2, Mac OS X v10.3, Mac OS X v10.4 or higher; PowerPC G3 or Intel Core Processor; 256 MB RAM; 1 GB available hard disk space |
| Lijnnauwkeurigheid: | +/- 0,1% |
| Minimale systeemeisen: | Windows 2000: Intel Pentium III (733 MHz), 256 MB RAM, 2 GB available hard disk space; Windows XP Home, Windows XP Professional: Intel Pentium IV (1 GHz), 512 MB RAM, 2 GB available hard disk space
Windows 2000: Intel Pentium III (733 MHz), 512 MB RAM, 2 GB available hard disk space; Windows XP Home, Windows XP Professional: Intel Pentium IV (1 GHz), 512 MB RAM, 2 GB available hard disk space
Mac OS X v10.2, Mac OS X v10.3, Mac OS X v10.4 or higher; PowerPC G4, G5, or Intel Core Processor; 1 GB RAM; 2 GB available hard disk space |
| Ingebouwde webserver: | Ja |
| Elektromagnetische compatibiliteit: | Compliance for Class B products:EU (EMC Directive), USA (FCC Rules), Canada (DoC), Australia (ACA), New Zealand (MoC), China (CCC), Japan (VCCI); Certified as Class A product: Korea (MIC), Taiwan (BSMI) |
| Printerbeheer: | HP Web Jetadmin, HP Easy Print Care/Printer Utility |
| Veiligheid: | USA and Canada (CSA certified), EU (LVD and EN60950-1 compliant), Russia (GOST), Singapore (PSB), China (CCC), Argentina (IRAM), Mexico (NYCE) |
| Luchtdruk: | 0,69 mmH2O |
| Losse vellen, maximum uitvoer: | 66" |
| Printkwaliteit (kleur, standaardkwaliteit): | 600 x 600 DPI |
| Logistieke gegevens |
|---|
| Producten per pallet: | 1 stuk(s) |
| Pallet brutogewicht: | 143 kg |
| Spuitmondjes: | 1056 |
| Kleurbeheer: | HP Color Center, HP Vivera inks, Closed-loop color system |
| Printsnelheid kleurenafbeelding (presentatie, glanzend papier): | 2.8 m2/hr
30 ft2/hr |
| Printsnelheid kleurenafbeelding (concept, papier met coating): | 41 m2/hr
445 ft2/hr |
| Printsnelheid kleurenafbeelding (standaard, papier met coating): | 110 ft2/hr
10 m2/hr |
| Printsnelheid kleurenafbeelding (standaard, glanzend papier): | 72 ft2/hr
6.7 m2/hr |
| Printsnelheid: | 70 D prints per hour |
| Printsnelheid lijntekening in kleur (concept, A1, gewoon papier): | 52 A1 prints per hour |
| Printtijd lijntekening in zwart-wit (concept, metrisch, A1, gewoon papier): | 35 sec/page |
| Printtijd lijntekening in kleur (concept, A1): | 35 sec/page |
| Papierverwerking: | Roll feed, sheet feed |
| Maximale printlengte: | 91 m |
| Maximale lengte vel: | 1676.4 mm |
| Standaard mediaformaten: | A4, A3, A2, A1, A0 |
| Mediagewichten per papierpad: | 60 to 328 g/m2 |
| Aanbevolen mediagewicht: | 60 - 328 g/m? |
| Verwerking van uitvoer: | Sheetfed, roll feed, automatic cutter |
| Maximaal aantal papierladen: | 1 |
| Papierverwerking standaard/invoer: | Roll loading, single sheet rear tray |
| Papierverwerking standaard/uitvoer: | Basket |
| Ondermarge kopie: | 16.75 mm |
| Linkermarge kopie: | 5 mm |
| Rechtermarge kopie: | 5 mm |
| Bovenmarge kopie: | 5 mm |
| Ondersteunde mediaformaten: | A, B, C, D, E |
| Mediadikte (per papierpad): | Tray 1: up to 31.5 mil |
| Niet-bedrukbaar gebied (media op rol): | 0.2 x 0.2 x 0.2 x 0.2 in (borderless on photo papers) |
| Aanbevolen temperatuur bij gebruik: | 15 - 35 ?C |
| Hoogte, in bedrijf (brits/amerikaans): | 9842 ft |
| Maximum afmetingen (B x D x H): | 1770 x 732 x 1047 mm |
| Afmetingen pallet (B x D x H): | 1965 x 780 x 780 mm |
| Afmetingen, voetnoot (imperial): | printer with stand |
| Afmetingen, noot (metrisch): | printer with stand |
| Afmetingen pallet (B x D x H) (imperiaal): | 1963,4 x 779,8 x 779,8 mm (77.3 x 30.7 x 30.7") |
| Gewicht pallet (imperiaal): | 142,9 kg (315 lbs) |
| Gewicht (imperiaal): | printer with stand
189.0 lb |
| Afmetingen verpakking (B x D x H): | 1963,4 x 779,8 x 779,8 mm (77.3 x 30.7 x 30.7") |
| Gewicht verpakking (imperiaal): | 122,9 kg (271 lbs) |
| Lettertypen: | Roman configuration: 139 fonts; Kanji configuration: 243 fonts |
| Minimum lijndikte: | 0,0423 mm |
| Compatibele inkttypen, supplies: | HP Vivera inks |
| Geluidskracht: | 6.9 B(A) |
| Geluidsdruk: | 57 dB |
| Printkwaliteit (zwart, beste kwaliteit): | 2400 x 1200 DPI |
| Printkwaliteit (zwart, concept): | 600 DPI |
| Printkwaliteit (zwart, standaard): | 600 DPI |
| Driver-updates ? omschrijving: | Latest driver upgrade information available on http:// |
| Inktdruppel: | 6 pl (C, M, PK, G), 9 pl (Y, MK) |
| Bedieningspaneel: | 240 x 160 pixels grayscale graphical display with Asian fonts support, 4 direct-access buttons and 7 navigation buttons, 2 bi-colour lights (Ready, Processing, Attention, Error) |
| Technische details: | Attain exacting detail?with gray HP Vivera Ink and improved line accuracy to 0.1%, 0.067 mm minimum line width
Posters, presentations make a powerful impression?create hard-to-achieve tones with the Three-black ink set.
Count on consistent, professional prints with over 20 Original HP media substrates?designed with Vivera Inks.
Your work is preserved with the smudge-resistant prints produced by fast-drying HP Vivera Inks.
Print CAD & GIS projects quickly and accurately?up to 35 seconds/A1 page?with HP Scalable Printing Technology.
Send and print large jobs reliably over the network with in-printer processing architecture.
Present your professional best?HP Vivera Inks produce a wide range of colors, from vivid color to soft tones. |
| Akoestische emissie (standby): | 44 dB |
| Beschikbare LAN-drivers: | Novell NetWare 3.x/4.x clients |
| JetDirect compatibele producten: | Ja |
| Minimale lijndikte: | 0.002 in |
| Maximale lengte print de (imperiale): | 300 ft; Operating system and application dependent |
| Mediaformaten standaard (vellen, rollen): | 8.5 to 44-in wide sheets, 11 to 44-in rolls |
| Niet-bedrukbaar gebied (losse vellen): | 0.2 x 0.67 x 0.2 x 0.2 in |
| Maximum rolinvoer: | 1 |
